2.
Pin configurations
Pin name
A0 - A14
Function
Addresses
32-lead PLCC
Top view
28-lead PDIP
Top view
O0 - O7
Outputs
VPP
1
28
VCC
CE
OE
NC
Chip enable
Output enable
No connect
A6
A5
A4
A3
A2
A1
A0
NC
O0
5
6
7
8
9
10
11
12
13
29
28
27
26
25
24
23
22
21
A8
A9
A11
NC
OE
A1 0
CE
O7
O6
A12
A7
A6
A5
A4
A3
A2
A1
A0
O0
2
3
4
5
6
7
8
9
10
11
27
26
25
24
23
22
21
20
19
18
A14
A13
A8
A9
A1 1
OE
A1 0
CE
O7
O6
Note:
PLCC package pins 1
O1
O2
GND
12
13
14
17
16
15
O5
O4
O3
and 17 are “don’t
connect”
3.
System considerations
Switching between active and standby conditions via the chip enable pin may produce transient voltage excursions. Unless
accommodated by the system design, these transients may exceed datasheet limits, resulting in device non-conformance.
At a minimum, a 0.1μF, high-frequency, low inherent inductance, ceramic capacitor should be utilized for each device. This
capacitor should be connected between the V CC and ground terminals of the device, as close to the device as possible.
Additionally, to stabilize the supply voltage level on printed circuit boards with large EPROM arrays, a 4.7μF bulk electrolytic
capacitor should be utilized, again connected between the V CC and ground terminals. This capacitor should be positioned as
close as possible to the point where the power supply is connected to the array.
Figure 3-1.
Block diagram
2
Atmel AT27C256R
0014O–EPROM–10/11
